  •   Hikvision bullet DS-2XS3Q47G1-LDH/4G/C18S40 F4 (su saulės panele, 4G)

    Hikvision bullet DS-2XS3Q47G1-LDH/4G/C18S40 F4 (su saulės panele, 4G)

    Kodas: KIP47G1LDH4GC18S40F4
    Barkodas: 6942160416120
    Pasiteirauti apie prekę
    1228.17 €
    Netinka kaina? Siūlyk savo!
    Mažas prekės kiekis sandėlyje.
    Informuoti, kai prekę turėsime
    Likutis: 0 vnt.
    Lizingo skaičiuoklės
    • esto3
    • esto
    • 4 MP kamera
    • Su saulės kolektoriumi ir įmontuota baterija
    • 24/7 ColorVu spalvotas vaizdas
    • H.265+
    • LLTE-TDD / LTE-FDD / WCDMA / GSM 4G belaidžio tinklo perdavimas, palaiko mikro SIM kortelę
    • 4G (LTE-TDD / LTE-FDD / TD-SCDMA) ryšio palaikymas
  • Prekės aprašymas
    • Kamera
    • Sensorius1/3" Progressive Scan CMOS
    • Maks. rezoliucija2688 × 1520
    • Min. apšvietimasColor: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light
    • Užrakto greitis1/3 s to 1/100,000 s
    • Day & Night24/7 color imaging
    • Kampo keitimasSolar panel: pan: 0° to 358°, tilt: -40° to 0°; camera: pan: 0° to 340°, tilt: -5° to 105°
    • Lęšis
    • Lęšio tipasFixed focal lens, 4 and 6 mm optional
    • Rainelės tipasFixed
    • DiafragamaF1.0
    • Ryškumo gylis

      4 mm: 2.7 m to ∞

      6 mm: 5.9 m to ∞

    • Focal Length & FOV

      4 mm, Horizontal FOV: 75°, Vertical FOV: 40°, Diagonal FOV: 89°

      6 mm, Horizontal FOV: 49°, Vertical FOV: 27°, Diagonal FOV: 57°

    • Lęšio montavimasM12
    • DORI
    • DORI

      4 mm, D: 82 m, O: 32 m, R: 16 m, I: 8 m

      6 mm, D: 120 m, O: 47 m, R: 24 m, I: 12 m

    • Apšvietimas
    • Papildomo apšviešimo tipasWhite Light
    • Papildomo apšvietimo diapazonasPerformance mode: up to 30 m, proactive mode: up to 10 m
    • Išmanus papildomas apšvietimasYes
    • Vaizdas
    • Pagrindinis srautas

      50 Hz: 12.5 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

      60 Hz: 15 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

    • Antrinis srautas

      50 Hz: 12.5 fps (1280 × 720, 640 × 480, 640 × 360)

      60 Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360)

    • Vaizdo suspaudimas

      Main stream: H.265/ H.264

      Sub-stream: H.265/H.264/MJPEG

      H.264+ and H.265+: main stream supports under performance mode

    • Vaizdo bitų greitis32 Kbps to 8 Mbps
    • H.264 tipasBaseline Profile,Main Profile,High Profile
    • H.265 tipasMain Profile
    • Bitų greičio kontrolėCBR,VBR
    • Region of Interest (ROI)1 fixed region for main stream
    • Scalable Video Coding (SVC)H.264 and H.265 encoding
    • Garsas
    • Garso atrankos dažnis8 kHz/16 kHz
    • Pašalinių garsų šalinimasYes
    • Garso suspaudimasG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3
    • Garso bitų greitis64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
    • Internetas
    • SaugumasPassword protection, complicated password, basic and digest authentication for HTTP, TLS 1.1/1.2/1.3, WSSE and digest authentication for Open Network Video Interface
    • Tiesioginis vaizdo žiūrėjimasUp to 6 channels
    • APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK
    • ProtokolaiTCP/IP, ICMP, HTTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP
    • User/Host

      Up to 32 users

      3 user levels: administrator, operator, and user

    • Vidinė atmintisAuto Network Replenishment (ANR)
    • KlientasiVMS-4200,Hik-Connect,Hik-Central
    • Naršyklė

      Plug-in required live view: IE 10, IE11,

      Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,

      Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

    • Mobile Communication
    • SIM Card TypeMicro SIM
    • Uplink and Downlink Data RateCat 4, uplink: 50 Mbps, downlink: 150 Mbps
    • Dažnis

      EU:

      LTE-TDD: B38/B40/B41

      LTE-FDD: B1/B3/B5/B7/B8/B20/B28

      WCDMA: B1/B5/B8

      GSM: B3/B5/B8

      LA:

      LTE-TDD: B38/B40

      LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B17/B28/B66

      WCDMA:B1/B2/B3/B4/B5/B8

      GSM: B2/B3/B5/B8

      US:

      LTE-FDD: B2/B4/B5/B12/B13/B17/B66/B71

      WCDMA: B2/B4/B5

    • StandartasLTE-TDD,LTE-FDD,WCDMA,GSM
    • Nuotrauka
    • SNR≥ 52 dB
    • Wide Dynamic Range (WDR)120 dB
    • Privatumo kaukė4 programmable polygon privacy masks
    • Diena/Naktis režimasDay,Night,Auto,Schedule
    • Nuotraukų pagražinimasBLC,HLC,3D DNR
    • Nuotraukos nustatymaiRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
    • Sąsaja
    • Interneto sąsaja1 RJ45 10 M/100 M self-adaptive Ethernet port
    • Vidinė atmintis

      Built-in eMMC storage, up to 64 GB,

      Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB,For eMMC storage, 50 GB is available for recording.

    • Įmontuotas mikrofonasYes
    • Įmontuotas garsiakalbisYes
    • Perkrovimo mygtukasYes
    • Funkcijos
    • Pagrindinės funckcijosMotion detection,video tampering alarm,network disconnected,IP address conflict,illegal login,HDD full,HDD error
    • SąsajaUpload to NAS/memory card,notify surveillance center,trigger recording,trigger capture,audible warning
    • Pagrindinis
    • Sistemos parametrai

      Power Consumption and Current:

      Typical power scenarios: 1.85 W (4G working)

      Standby scenarios: 40 mW

      Max. power consumption: 6 W

      Power Supply:

      12 VDC ± 25%

      *For debugging only

      40 W (deviation: ± 2 W) Solar panels

      Power Interface:

      Power supply interface: Ø5.5 mm coaxial power plug

      Extened solar panel: four-core aviation connector

    • MedžiagaCamera: Plastic; Solar panel: Metal
    • Sandėliavimo sąlygos-20 °C to 50 °C (-4 °F to 122 °F). Humidity 95% or less (non-condensing)
    • Kalba33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
    • Pagrindinės funkcijosHeartbeat,mirror,flash log
    • Darbo sąlygos-20 °C to 50 °C (-4 °F to 122 °F). Humidity 95% or less (non-condensing)
    • Dydis686.6 mm × 442.6 mm × 760 mm (27.03" × 17.42" × 29.9")
    • Pakuotės dydis902 mm × 342 mm × 440 mm (35.5" × 13.5" × 17.3")
    • Svoris

      Approx. 11.70 kg (25.8 lb.)

    • Svoris su įpakavimu

      Approx. 15.01 kg (33.1 lb.)

    • Baterija
    • Baterijos tipasTernary Lithium
    • Talpa8.4 Ah × 2 packs
    • Maks. Įkrovimo įtampa12.6 V
    • Darbo sąlygos (temperatūra)

      Charging: -20 °C to 45 °C (-4 °F to 113 °F)

      Discharging: -20 °C to 55 °C (-4 °F to 131 °F)

    • Baterijos įtampa9 V to 12.6 V
    • Baterijos veikimo laikasMore than 500 cycles
    • Ciklo tarnavimo laikas

      Performance mode: 3.6 days,

      Proactive mode: 6 days,

      Standby mode: 30 days

    • Baterijos svorisApprox. 1400 g (3.1 lb.)
    • Patvirtinimai
    • EMC

      CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,

      RCM: AS/NZS CISPR 32: 2015,

      IC: ICES-003: Issue 7,

      *IC certification is only for the device sold in the North American region. CE and RCM certifications are only for the device sold in the European region.

    • RF

      IC ID (RSS-247(BT or 2.4G)),

      CE-RED: EN 301489-1 V2.1.1 (BT or 2.4G), EN 301489-17 V3.1.1 (BT or 2.4G), EN 300328 V2.1.1 (BT or 2.4G), EN 62311: 2008 (BT or 2.4G)

      *IC certification is only for the device sold in the North American region. CE certification is only for the device sold in the European region.

    • Saugumas

      CB: IEC 62368-1: 2014+A11,

      CE-LVD: EN 62368-1: 2014/A11: 2017,

      LOA: IEC/EN 60950-1,

      *CE and LOA certifications are only for the device sold in the European region.

    • Aplinkosauga

      CE-RoHS: 2011/65/EU,

      WEEE: 2012/19/EU,

      Reach: Regulation (EC) No 1907/2006,

      *CE certification is only for the device sold in the European region.

    • Apsauga

      IP65: IEC60529-2013
