  •   6 prievadų, 4 PoE komutatorius UTP6306S-PSB

    6 prievadų, 4 PoE komutatorius UTP6306S-PSB

    Kodas: SWITCHUTP6306S-PSB
    Pasiteirauti apie prekę
    193.29 €
    Netinka kaina? Siūlyk savo!
    Šią prekę turime sandėlyje.
    Likutis: 5 vnt.
    Lizingo skaičiuoklės
    • esto3
    • esto
    • 4*10/100/1000 Base-T PoE RJ-45 prievadai
    • 2*1000 Base-X SFP prievadų
    • 1*RJ-45 konsolės prievadas
    • Darbinė temperatūra: -40 ℃ ~ 75 ℃
    • Perteklinis maitinimo šaltinis
    • 8kV kontaktinis išlydis, 12kV oro iškrovimas ESD apsauga
    • Metalinio korpuso dizainas be ventiliatoriaus
    • DIN bėgelio montavimas
    • Prekės aprašymas
      • Pagrindinis
      • ĮrenginysUTP3306TS-PSD
      • Downlink prievadai4*10/100/1000 Base-T PoE++ RJ-45(Auto-MDI/MDI-X)
      • Uplink prievadai1*10/100/1000 Base-T RJ-451*1000 Base-X SFP
      • Led indikatoriai1*PWR, power supply indicators1*Link/Act, SFP port state indicators
      • Dydis294mm*180mm*44mm
      • Įeinanti įtampa100~240V AC, 50~60Hz
      • Energijos sunaudojimas≤370W (Full load including PoE)
      • MedžiagaMetal shell
      • MontavimasRack/Desktop/Wall mounted
      • StandartaiIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
      • Persiuntimo režimaiStore and Forward
      • MAC adresų lentelė2k, support auto learning
      • Perjungimo talpa12Gbps/non-blocking
      • Paketų persiuntimo greitis8.928Mpps
      • Port Buffer1MB
      • Jumbo Frame9716 Bytes
      • PoE standartasIEEE 802.3af/at/bt
      • PoE maitinimo tipasEnd-span
      • PoE išdėstymas3/6/4/5(+), 1/2/7/8(-)
      • PoE biudžetas90W max for each port, 360W max for whole switch
      • Darbo sąlygos temepratūra-10℃~50℃, 5%~95% (Non-condensation)
      • Saugykla-40℃~70℃, 5%~95% (Non-condensation)
      • SertifikataiCE, FCC
      • Sistemos informacijaSystem, Hardware, Time and Firmware
      • IP būsenaIP Interfaces, IP Routes and  ARP Table
      • Sistemos pranešimaiSystem Log Information
      • Detalūs sistemos pranešimaiID and Message
      • MAC adresų lentelėMAC Address Table: Type, VLAN, MAC Address, CPU and Port Number
      • VLANsMembership and Ports
      • PrievadaiTraffic Overview and Detailed Statistics
      • LACPSystem Status, Port Status and Port Statistics
      • Apsauga nuo perkaitimoThermal Protection Port Status
      • Green EthernetPort Power Savings Status
      • PoE statusasPower Over Ethernet Status
      • LLDPThermal Protection Port Status
      • Loop ProtectionLoop Protection Status
      • Aprėpiantys protokolaiBridge Status, Port Status and Port Statistics
      • IGMP SnoopingIGMP Snooping Status, Groups Information and IPv4 SFM Information
      • MLD SnoopingMLD Snooping Status, Groups Information and IPv6 SFM Information
      • DHCPServer, Snooping Table, Relay Statistics and Detailed Statistics
      • SaugumasPort Security, Access Management Statistics, 802.1X, ACL Status and AAA
      • QoSQoS Statistics and QCL Status
      • IP ConfigIP Configuration, IP Interfaces and IP Routes
      • IP būsenaIP Interfaces, IP Routes and ARP Table
      • DHCP serverisDHCP Server Mode Configuration, Excluded IP and Pool
      • NTPNTP Configuration
      • TimezoneSystem Timezone Offset and UTC time
      • SNMPSystem, Trap, Communities, Users, Groups, Views and Access
      • Sistemos pranešimaiSystem Log Configuration
      • PrievadaiPort Configuration
      • AggregationStatic and LACP
      • MirroringMirror and Mirror Port Configuration
      • Apsauga nuo perkaitimoThermal Protection Configuration
      • Green EthernetPort Power Savings and Port Configuration
      • DDMDDM Configuration, DDM Overview and DDM Detailed
      • PoE nuostataiPower Over Ethernet, PoE Power Supply and PoE Port Configuration
      • PoE statusasPower Over Ethernet Status
      • MAC adresų lentelėAging Configuration, MAC Table Learning and Static MAC Table Configuration
      • PTPPTP Clock Configuration and PTP Status
      • VLANsGlobal VLAN and Port VLAN Configuration
      • Balso VLANVoice VLAN Configuration and Voice VLAN OUI Table
      • GVRPGVRP Global and Port Configuration
      • Prievado izoliacijaPort Group and Port Isolation
      • Loop ProtectionGeneral Settings and Port Configuration
      • Aprėpiantys protokolaiBridge Settings, MSTI Mapping, MSTI Priorities, CIST Ports and MSTI Ports
      • IPMC profilisProfile Table and Address Entry
      • MEPMaintenance Entity Point
      • ERPSEthernet Rapid Ring Protection Switching
      • IGMP SnoopingBasic Configuration, VLAN Configuration and Port Filtering Profile
      • IPV6 MLD SnoopingBasic Configuration, VLAN Configuration and Port Filtering Profile
      • LLDPLLDP Parameters and LLDP Interface Configuration
      • VartotojaiUsers Configuration
      • Privilegijų lygiaiPrivilege Level Configuration
      • SSHSSH Configuration
      • HTTPSHTTPS Configuration
      • Prievado saugumo ribaSystem and Port Configuration
      • Prieigos valdymasAccess Management Configuration
      • 802.1XNetwork Access Server Configuration
      • ACLPorts, Rate Limiters and Access Control List
      • ARP InspectionPort Configuration, VLAN Configuration, Static Table and Dynamic TableAAA RADIUS and TACACS+
      • Port ClassificationQoS Ingress Port Classification
      • Prievado politikaQoS Ingress Port Policers
      • Eilės politikaQoS Ingress Queue Policers
      • Prievado planavimasQoS Egress Port Schedulers
      • Prievado formavimas (port shaping)QoS Egress Port Shapers
      • Prievado žymos žymėjimasQoS Egress Port Tag Remarking
      • Prievado DSCPQoS Port DSCP Configuration
      • DSCP-Based QoSDSCP-Based QoS Ingress Classification
      • DSCP vertimasDSCP vertimas
      • DSCP klasifikacijaDSCP klasifikacija
      • QoS valdymo sąrašasQoS Control List Configuration
      • Storm PolicingGlobal Storm Policer Configuration
      • PingICMP Ping
      • Kabelio diagnostikaCable Status
      • Procesoriaus apkrovaCPU Load Information
      • Įrenginio paleidimas iš naujonRestart the Device
      • Gamykliniai nustatymaiGamykliniai nustatymai
      • Programinės įrangos atnaujinimasSoftware Upload
      • Programinės įrangos pasirinkimasSoftware Image Selection
      • KonfigūracijaDownload, Upload, Activate and Delete
